ifm electronic Inductive Block Proximity Sensor, 2 mm Detection, PNP NO, 10 → 36 V dc
Tehniskie dokumenti
Specifikācija
Brand
ifm electronicSensor Technology
Inductive
Detection Range
2 mm
Body Style
Block
Output Function
NO
Digital Switching Output Type
PNP
Connection Type
Pre-Cabled
Cable Length
2m
Supply Voltage
10 → 36 V dc
Length
40mm
IP Rating
IP65
Mounting Type
Flush
Housing Material
Bronze Plated Brass
Width
8mm
Maximum dc Voltage
36V
Minimum Operating Temperature
-25°C
Depth
8mm
Maximum Operating Temperature
+70°C
Shielding
Unshielded
Maximum Switching Frequency
2kHz
Switching Current
250 mA
Reverse Polarity Protection
Yes
Switching Frequency
2 kHz
Short Circuit Overload Protection
Yes
Izcelsmes valsts
Germany
Produkta apraksts
Inductive proximity switch, 8 x 8 x 40 mm
Block Style
Flush mounting, embeddable sensors with IP67 protection and an operating temperature range of -25 to +75°C. All have short circuit and reverse polarity protection and provide an LED indication of the on/off status.
€ 95,50
€ 95,50 Katrs (bez PVN)
€ 115,56
€ 115,56 Katrs (Ieskaitot PVN)
1
€ 95,50
€ 95,50 Katrs (bez PVN)
€ 115,56
€ 115,56 Katrs (Ieskaitot PVN)
1
Noliktavas stāvoklis patreiz nav pieejams
Lūdzu pārbaudiet vēlreiz vēlāk
